Setra SRMD Room Pressure Monitoring

Part Number: Setra SRMD Category:

Email Us:
WhatsApp Us: +6016-551 9084
WhatsApp Channel: Follow Our WhatsApp Channel

Setra SRMD Room Pressure Monitoring is designed to provide a prominent display in critical environments. The Setra SRMD takes inputs from critical sensors and displays the parameters in 1” illuminated LCD characters. Also, the sensor agnostic and accepts 0-5VDC or 0-10VDC inputs. However, it is also available to order calibrated with Setra humidity/temperature sensors, ensuring that it is ready to install out of the box, providing quick installation. The SRMD is available in the single or dual configuration with a white or nickel bezel, and the LCD characters are available in three colors; red, green, and blue.

Highly Visible LCD Display – Real-time environmental monitoring is essential in critical spaces such as operating rooms, laboratories, or medical manufacturing clean rooms. The SRMD is a display panel which takes sensor information and displays with 1” LCD characters. The SRMD is offered in either a single or dual display configuration with three color choices (red, green, blue) so that the end-user can see the critical parameters from up to 30’ away.

Installation Without Customization – The SRMD is designed to make things easy for both the installer and the end-user. The unit mounts in an off-the-shelf electrical box, making the installation simple once the job’s rough-in phase is complete. The SRMD accepts either a 0-5 or 0-10 VDC input, can be calibrated for any parameter and is powered by either 24 volts DC or AC.

Let Setra Perform the Calibration – The installer has enough to think about on the job site, so let Setra take some of the burdens. When paired with Setra’s SRH relative humidity sensors, the SRMD comes pre-configured and ready for installation out of the box. The SRMD drastically reduces the installation time needed for the application.

  • Single of Dual Display with White Bezel or Silver
  • 1” Illuminated LCD Characters – Red, Green or Blue
  • IP-54 Wipe Down Design for Critical Applications
  • Fits into Off-the-Shelf Electrical Gang Box
  • Compatible with any Analog 0-5VDC or 0-10VDC Output

Data Sheet:Setra_Model_SRMD_Data_Sheet
Instruction Manual:Setra_Model_SRMD_Operating_Instructions
