Name: Gems Sensors FS-600 Thermal Dispersion Flow Switch
Brand: Gems Sensors
SKU: Gems Sensors FS-600
Availability: InStock

Gems Sensors 230500-1-10

Flow Setting: 0.24 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-15

Flow Setting: 0.35 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-20

Flow Setting: 0.46 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-25

Flow Setting: 0.57 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-30

Flow Setting: 0.68 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-35

Flow Setting: 0.68 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-40

Flow Setting: 0.90 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-45

Flow Setting: 1.01 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-05

Flow Setting: 0.13 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-50

Flow Setting: 1.12 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-55

Flow Setting: 1.23 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-1-60

Flow Setting: 1.34 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-10

Flow Setting: 0.57 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-15

Flow Setting: 0.79 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-20

Flow Setting: 1.01 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-25

Flow Setting: 1.23 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-30

Flow Setting: 1.46 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-35

Flow Setting: 1.68 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-40

Flow Setting: 1.90 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-45

Flow Setting: 2.12 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-05

Flow Setting: 0.35 GPM
Body Material: 316 Stainless Steel
Port Size: 1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-50

Flow Setting: 2.34 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-55

Flow Setting: 2.57 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-2-60

Flow Setting: 2.79 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-10

Flow Setting: 0.97 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-15

Flow Setting: 1.31 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-20

Flow Setting: 1.65 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-25

Flow Setting: 1.99 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-30

Flow Setting: 2.32 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-35

Flow Setting: 2.66 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-40

Flow Setting: 3.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-45

Flow Setting: 3.33 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-05

Flow Setting: 0.64 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-50

Flow Setting: 3.67 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-55

Flow Setting: 4.01 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-3-60

Flow Setting: 4.34 GPM
Body Material: 316 Stainless Steel
Port Size: 1" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-10

Flow Setting: 2.28 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-15

Flow Setting: 3.07 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-20

Flow Setting: 3.86 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-25

Flow Setting: 4.66 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-30

Flow Setting: 5.45 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-35

Flow Setting: 6.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-40

Flow Setting: 7.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-45

Flow Setting: 8.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-05

Flow Setting: 1.48 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-50

Flow Setting: 9.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-55

Flow Setting: 10.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1-1/2" NPT Female
Switch Type: SPST (30 VAC @ 45 ma, 42 VDC @ 65 ma)

Gems Sensors 230500-4-60

Flow Setting(GPM): 11.00 GPM
Body Material: 316 Stainless Steel
Port Size: 1 1/2" NPT Female
Switch Type: SPST (30VAC @ 45mA, 42VDC @ 65mA)

Gems FS-600 No-Moving Part Series Flow Switch is a solid state sensor that is compatible with both conductive and non-conductive fluids, as well as fluids with particulates or slurries. FS-600 is immune to changes in media viscosity and the straight through switch is designed for a long life and can be mounted in any orientation and can handle a wide range of flow rates.

Download Gems Sensors 230500-1-10 information here

Datasheet: Gems FS600 Series Datasheet
Manual: Gems FS-600 Manual
