E+E HTS801 Humidity and Temperature Sensor for High Humidity and Chemically Polluted Conditions
For the toughest industrial humidity applications, the E+E HTS801 delivers accurate, long-term stable measurement from −80 °C to 180 °C (−112 °F to 356 °F) and up to 300 bar (4,351 psi), even in extremely humid or chemically polluted environments.
How It Works
A heated, monolithic E+E RH/T sensing element with proprietary coating recovers quickly after condensation or chemical contamination. Intelligent rapidX smart probes upload their own parameters when connected, so a damaged probe can be swapped, even during operation, without configuration, adjustment or calibration.
Key Features
- Range −80 °C to 180 °C (−112 °F to 356 °F), up to 300 bar (4,351 psi)
- Heated sensing element with selectable heating modes
- rapidX smart probes: hot-swappable without recalibration
- Six versions with several probe and cable lengths
- IP65 / NEMA 4X polycarbonate or stainless steel enclosure
- Two scalable analogue outputs, RS485 (Modbus RTU) or Ethernet-PoE (Modbus TCP), alarm relays
- Optional 3.5″ colour display; configuration via free PCS10 software
Applications
- Agricultural and building-material drying
- High-humidity storage rooms
- Climate, test and curing chambers
- Meteorology for NMIs and ice-warning systems
- Fuel cell and automotive test benches
- Pharmaceutical and chemical processes
Industries Served
- Process industry
- Automotive and energy testing
- Pharmaceutical and chemical
- Meteorology
Frequently Asked Questions
What are the operating limits of the HTS801?
−80 °C to 180 °C (−112 °F to 356 °F) and pressures up to 300 bar (4,351 psi).
What are rapidX smart probes?
Plug-and-play probes that upload their parameters automatically, so they can be replaced, even during operation, without configuration, adjustment or calibration.
Need help choosing the right E+E HTS801 configuration? Contact Celectric for a quotation, datasheet and technical support in Malaysia.
