Gems XLS-1 Ultrasonic Level Sensor

Gems 251070

$251

Actuation Level N/A
Switch Operation Wet Source
Min. Liquid N/A
Stem Material Stainless Steel
Float Material N/A
Float Diameter N/A
Mounting Size 1/2′-20 per SAE J1926-3
Mounting Horizontal
Switch Type TTL/CMOS Compatible
Input 5-20 VDC
Output Open Collector Sourcing 30 Ma @ 30 VDC
Maximum Pressure (PSI) 250
Minimum Temperature (°F) -40
Maximum Temperature (°F) 257
Electrical Termination 12″-14″ PVC Cable
Wetted Materials 316L Stainless Steel, EPDM. 30% Glass Filled Polyester
Approvals CE, RoHS, UL/cIL Recognized



Data Sheet: Gems_XLS1-1-Datasheet
Instruction Manual: Gems_XLS-1_Manual
