Actuation Level N/A
Switch Operation Wet Sink
Min. Liquid N/A
Stem Material Stainless Steel
Float Material N/A
Float Diameter N/A
Mounting Size 1/4″-18 NPT
Mounting Horizontal
Switch Type TTL/CMOS Compatible
Input 5-28 VDC
Output Open Collector Sink 30 Ma @ 30 VDC
Maximum Pressure (PSI) 250
Minimum Temperature (°F) -40
Maximum Temperature (°F) 257
Electrical Termination Integral 3-pin Deutsch Connector
Wetted Materials 316L Stainless Steel, EPDM. 30% Glass Filled Polyester
Approvals CE, RoHS, UL/cIL Recognized
