Gems RFO Type Electronic Flow Sensor

Gems 194763


Flow Range: 5.0 – 30.0 GPM
Body Material: 316 Stainless Steel
Port Size: 3/4″ NPT Female

Availability: 4 in stock

Sensor TypeRotorFlow
Standard Flow Range (GPM)5.0 – 30.0
Flow Range (GPM)5.0 – 30.0
Body Material316 Stainless Steel
Port Size3/4″ NPT Female
Input Power4.5 VDC to 24 VDC
Output4.5 VDC to 24 VDC Pulse (Sourcing)
Low Flow Accuracy±15%
Standard Flow Accuracy±15%
Maximum Pressure (PSI)200
Minimum Temperature (°F)-20
Maximum Temperature (°F)212
Electrical Termination22 AWG, 24″-24″ PVC Cable
Wetted Materials316 Stainless Steel, PPS Composite, Polysulfone, Viton (Low Flow Adapter – Polypropylene)
ApprovalsUL Recognized, CE, CUL Recognized
Recommended Filtration150 micron

Datasheet: Gems_RFO-Types-datasheet
Instruction Manual: Gems_RFO-RFA_Manual
