Actuation Level 2-8mm
Switch Operation Normally Open Dry
Min. Liquid N/A
Stem Material Valox
Float Material N/A
Float Diameter N/A
Mounting Size M18x1
Mounting Non-Contact
Switch Type L-type, Non-Embeddable
Input 5-48 vdc
Output Current Sourcing PNP, Max Load Current 300 ma
Maximum Pressure (PSI) N/A
Minimum Temperature (°F) -13
Maximum Temperature (°F) 158
Electrical Termination 78.74″ 3 wWire PVC
Wetted Materials N/A
Approvals CE
